Brief introduction:
3 Sides Full Auto Pad Printing Machine For Sizer is customized and applicable to printing 3 Sides Sizer .With special jig, can print 3 different faces for one color or 3 colors, it can print 6 pcs of sizer at one time, high efficiency, accurate registration, stable performance and etc .
Main parts of this machine:
★PLC controller with easy operation.
★Print head can be changed flexibility.
★Using famous brand of precise pneumatic parts .
Main function:
★AUTO Hopper
★AUTO Sizer Arranging Unit
★Anti-Static Dust Clean Unit
★3 Sides Printing Unit
★Hot Wind Drying Unit
★AUTO Off-loading Unit
Technical Parameter:
★Plate Size: 100*150mm
★MAX Running Speed: About 7200 pcs per hour (Actual printing speed
depends on actual printing condition )
★Soft Pad Diameter: 90mm
★Max Soft Pad Diameter: 90mm
★Air Pressure: 5 bar
★Power Supply : AC220V Single Phase 50/60HZ
★Machine Dimension : L1500*W1200*H1600mm
★Auto Feeder Dimension : L1000*W800*H1600mm
★Machine weight: About 530KGS
★Auto Feeder Weight : About 70KGS
