Description：

■ HT-4060-V is especially designed for thin and flat surface material, with vacuum which can absorb the work piece firmly without any movement so as to make high-precision printing.

■ HT-4060-F is especially designed for the flat surface material with high-precision, correct overlapping and easy for loading and unloading with high efficiency.

Main parts:

■ Micro computer controls all functions and actions, high level of automation and easy operation.

■ Four-digit automatic counter

■ Adjustable printing stroke and speed, can meet all different printing requests..

■ The title angle of working table can be adjusted slightly up-and-down, left-and-right and level. very convenient to calibrate.

■ Printing & ink-return are controlled by pneumatic system with pressure adjustment function.

■ Steady micro computer controller.

■ Bright & clear blue monitor to show machine status at any time.

■ High qualified ‘AUTONICS’ sensor & perfect error alarm system.

■ Convenient foot switch, easy to operate and maintenance.

■ Use light but strong die-casting alloy components & imported wearable bearing & spindle sleeve.

■ SMC、FESTO and other international famous brands as pneumatic parts.

■ Separated speed control for printing and ink-return

Technical Parameter ：

HT-4060-V

◆ Max printing size：≤300 mm x 500mm

◆ Max printing thickness：≤200 mm

◆ Max printing speed：1000pcs/hour

◆ Power supply：AC220V 50/60Hz

◆ Rated power：450W

◆ Air pressure:：5～7bar

◆ Machine size：1000mmx800mmx1650mm

◆ Machine weight：320 kg

HT-4060-F

◆ Max printing size：≤300 mm x 500mm

◆ Max printing thickness：≤200 mm

◆ Max printing speed：1000pcs/hour

◆ Power supply：AC220V 50/60Hz

◆ Rated power：450W

◆ Air pressure:：5～7bar

◆ Machine size：1000mmx800mmx1650mm

◆ Machine weight：320 kg

Printed Producers Sample Picture：

Video：
